Plate Link Belt Ⅱ

Plate belt made of stainless steel and chain by sprocket is perfect for conveying small products,its smooth running, easy to maintain, durable, constructed of plates or hinges linked together by means of cross rods. The belt is almost always equipped with side chains,which are secured by a ring welded at the edge of cross rods .

Description

welded wire mesh belt with chain
balanced weave wire mesh belt
small gap, transportation small items

Material

1Cr13 mesh belt, 201 mesh belt, 304 mesh belt, mesh belt 316,engineering plastics,etc.

Specifications

Type of chian	Pitch	Thickness of chain	Length of chain	Diameter of shaft
128F	19.05	12.	250	4
C2042	25.4	2	250	4
C2052	31.75	2	As unique request	5
C2062	38.1	2		5.96
C2082	50.8	2.5		7.94
C2012	63.5	2.5		9.54
C2122	76.2	3		11.1
C05100	100	3		11.3
C10150	150	4		14.5
C12200	200	4.5		15.9

The specification above is just for reference,please contact us to meet your unique special needs

Key using industries

food, medicines, beverages, canned food, cosmetics and washing products, paper products, seasoning, dairy and tobacco automatic conveying, distribution, and packaging line
